Mach & Salcher Publish the First Supersonic Image; The Mach Angle and Mach Number

1877
Salcher's original photograph of supersonic images.
Salcher's original photograph of supersonic images.

In 1877 Austrian physicists Ernst Mach and Peter Salcher in Prague published "Photographische Fixirung der durch Projectile in der Luft eingeleiteten Vorgänge," Sitzungsber. k. Akad. Wiss., math.-naturwiss. Classe, 95 (1887) 764-80. The paper reproduced the first photograph of a shock wave in front of an object (in this case a bullet) moving at supersonic speed, and the first mathematical formula describing the physics of the shock wave.

"At the request of Ernst Mach, who had not managed to experimentally prove his shockwave theory, Salcher and his assistant Sandor Riegler, who was then a professor of chemistry and physics at the Rijeka Higher Commercial School, conceived in 1886 an experiment where he managed to record the flight of a projectile shot from a firearm for the first time in history using a specially devised ultra-fast photography technique. The recording was done using a method invented in 1859-64 by August Toepler, Salcher's professor from Graz. The short exposure was achieved using an electric spark, and a total of 80 shots were recorded. Salcher, in collaboration with Ernst Mach, published the results of this experiment in the 1887 paper Photographic recording of phenomena caused by the flight of projectiles through the air (Photographische Fixirung der durch Projectile in der Luft eingeleiteten Vorgänge)" (Wikipedia article on Peter Salcher, accessed 9-2020).

“The angle α, which the shock wave surrounding the envelope of an advancing gas cone makes with the direction of its motion, was shown to be related to the velocity of sound ν and the velocity of the projectile ω as sinα = ν/ω when ω > ν. After 1907, following the work of Ludwig Prandtl at the Kaiser Wilhelm Institut für Strömungsforschung in Göttingen, the angle α was called the Mach angle. Recognizing that the value of ω/ν (the ratio of the speed of an object to the speed of sound in the undisturbed medium in which the object is traveling) was becoming increasingly significant in aerodynamics for high-speed projectile studies, J. Ackeret in his inaugural lecture in 1929 as Privatdozent at the Eidgenössischen Technische Hochschule, Zürich, suggested the term ‘Mach number’ for this ratio" (Dictonary of Scientific Biography).

Anderson, History of Aerodynamics (1999) 376.
