A drawing by Sandin of the Sayre Glove is reproduced on the left side of this photocopy od a section of a page of Sturman & Zeltzer

A drawing by Sandin of the Sayre Glove is reproduced on the left side of this photocopy od a section of a page of Sturman & Zeltzer's paper, "A Survey of Glove-based Input," IEEE Computer Graphics & Applications (January 1994) 30-39.

Detail map of Chicago, Illinois, United States Overview map of Chicago, Illinois, United States

A: Chicago, Illinois, United States

Daniel J. Sandlin Invents the Sayre Glove

1977

In 1977 Daniel J. Sandin and Thomas Defanti at the Electronic Visualization Laboratory, a cross-disciplinary research lab at the University of Illinois at Chicago, created the Sayre Glove, the first wired glove or data glove. The glove was based on an idea of a colleague at the laboratory, Richard Sayre.  An inexpensive, lightweight glove to monitor hand movements, the Sayre Glove provided an effective method for multidimensional control, such as mimicking a set of sliders.

"This device used light based sensors with flexible tubes with a light source at one end and a photocell at the other. As the fingers were bent, the amount of light that hit the photocells varied, thus providing a measure of finger flexion. It was mainly used to manipulate sliders, but was lightweight and inexpensive" (Wikipedia article on Daniel J. Sandin, accessed 10-03-2013).

This may the beginning of gesture recognition research in computer science.
